MJI10, MJI18, MJI19 – Hand & Hydraulically Torque & Tension Bolted Connection Techniques

Course Objectives

• Demonstrate compliance with health and safety requirements and approved working practices
• Understand the quality control systems and procedures to be employed during the dismantling, preparation and securing of bolted connection systems
• Prepare work areas, equipment and materials for the dismantling, preparation and securing of bolted connection systems
• Dismantle hand torqued, hydraulically torqued and tensioned bolted connection systems
• Remove and replace components relating to hand torqued, hydraulically torqued and tensioned bolted connection systems
• Assemble, secure and tighten hand torqued, hydraulically torqued and tensioned bolted connections
• Verify the integrity of the assembled joint
• Reinstate the work area, equipment and materials

Who Should Attend?

Engineers/Technicians who will be involved in the use of hand, hydraulic torque and tensioning equipment.

Course Content

The new technical training standards and 4 Stage Mechanical Joint Integrity Training and Competency Model by ECITB:

STAGE 1

• MJI10 – Hand Torque Bolted Connections – Dismantle, prepare and secure hand torque bolted connections.
• MJI18 – Hydraulically Tension Bolted Connections – Dismantling, assemble and tension bolted connections using hydraulic tensioning equipment.
• MJI19 – Dismantling, Assembling and Tightening Bolted Connections – Dismantle, assemble and tighten bolted connections using powered torque equipment

STAGE 2

Work Based Task Assignments

A new approach to the workplace consolidation of knowledge has been developed; Work Based Task Assignments. Each assignment lists the activities to be undertaken by the learner and validated by the supervisor.

Three work based task assignments have been approved by the ECITB:

• Dismantle, Assemble and Hand Torque Bolted Connections
• Dismantle, Assemble and Hydraulically Tension Bolted Connections
• Dismantle, Assemble and Hydraulically Torque Bolted Connections

The task assignments are normally completed between three to twelve months after the initial training course and the learner can then undertake an ECITB approved Technical Test.

STAGE 3

Technical Testing with an associated ECITB certificate of achievement plays a key role in validating an Individual’s skill, ability and job knowledge in a specific task area. Each test consists of a knowledge test and practical activity test against identified test criteria and are grant aided for ECITB registered employers:

There are five ECITB approved Technical Tests covering the mechanical joint integrity:

• TMJI10 Dismantle, Assemble and Hand Torque Flanged Joints – 1.5 hours duration
• TMJI11 Dismantle, Assemble and Hand Torque Clamp Connectors – 1.5 hours duration
• TMJI18 Dismantle, Assemble and Tensioning Bolted Connections (Hydraulic Tensioning) – 1.5 hours duration
• TMJI 19 Dismantle, Assemble and Hydraulically Torque Flanged Joints– 1.5 hours duration
• TMJI 20 Dismantle, Assemble and Hydraulically Torque Clamp Connector Joints– 1.5 hours duration

STAGE 4

Repeat Tests Every 3 Years
